The TL062CDT from STMicroelectronics is a low-power, JFET-input dual operational amplifier in an SO-8 package. Featuring high input impedance and low power consumption, this device is optimized for battery-powered applications, audio processing, and precision signal conditioning.
| Parameter | Value | Unit |
|---|---|---|
| Supply Voltage Range | ±5V to ±18V | V |
| Input Offset Voltage | 6 (max) | mV |
| Input Bias Current | 30 (typ) | pA |
| Gain Bandwidth Product | 1 (typ) | MHz |
| Slew Rate | 3.5 (typ) | V/μs |
| Input Noise Voltage | 25 (typ) | nV/√Hz |
| Quiescent Current | 0.2 (typ) | mA/ch |
| Operating Temperature | 0°C to +70°C | °C |
| Package | SO-8 | – |
