The LM26LVCISD-105/NOPB from Texas Instruments is a precision, low-voltage temperature switch in a SOT-23-5 package. This device features ±0.5°C typical accuracy and a digital output, making it ideal for system protection, thermal management, and temperature monitoring in space-constrained applications.
| Parameter | Value | Unit |
|---|---|---|
| Supply Voltage Range | 2.7V to 5.5V | V |
| Temperature Threshold | 105°C (fixed) | °C |
| Accuracy (typ) | ±0.5 | °C |
| Accuracy (max) | ±2.5 | °C |
| Hysteresis | 5 (typ) | °C |
| Output Current | 5 (max) | mA |
| Quiescent Current | 35 (typ) | μA |
| Operating Temperature | -40°C to +150°C | °C |
| Package | SOT-23-5 | – |
