The H10721-01 is a compact photomultiplier tube (PMT) module developed by Hamamatsu Photonics. It integrates a high-voltage power supply and signal processing circuitry, and is optimized for low-light detection and time-resolved measurements.
| Parameter | Specification | Unit | Test Condition |
|---|---|---|---|
| Detector Type | Side-on PMT (R7899) | – | – |
| Spectral Response | 185–850 | nm | – |
| Cathode Sensitivity | 70 | μA/lm | @400nm |
| Anode Sensitivity | 5×10⁵ | A/lm | – |
| Gain | 10⁵–10⁷ | – | Adjustable voltage |
| Dark Current | ≤1 | nA | @25°C |
| Rise Time | 2.2 | ns | – |
| Output Signal | 0–10V analog voltage | – | 50Ω output impedance |
| Operating Voltage | +12 | VDC | Power <1.5W |
| Operating Temp. | -10 to +50 | °C | – |
