-Typical 1dB bandwidth of 2.3 MHz
-High attenuation
-Single Ended Operation
-Surface Mounted Package (SMD)
| RoomTemperature : +25°C | Minimum | Typical | Maximum | |
| Center Frequency (fo) | MHz | 70 | ||
| Insertion Loss | dB | 23.5 | 25.5 | |
| 1dB Bandwidth 3dB Bandwidth 40dB Bandwidth |
MHz MHz MHz |
2.2 – – |
2.37 2.6 3.6 |
3.75 |
| Amplitude Ripple (fo±10.0 MHz) Group Delay Variation (fo±10.0 MHz) |
dB nsec |
0.5 100 |
1 200 |
|
| Absolute Delay | usec | 2.45 | ||
| Ultimate Rejection | dB | 43 | 48 | |
| Temperature Coefficient of Frequency | ppm/°C | -0.03 | ||
