-Typical 1dB bandwidth of 22.05 MHz
-Low-Loss Filter
-Single Ended Operation
-Surface Mounted Package (SMD)
| RoomTemperature : +25°C | Minimum | Typical | Maximum | |
| Center Frequency (fo) | MHz | 75 | ||
| Insertion Loss | dB | 13.6 | 15.5 | |
| 1dB Bandwidth 3dB Bandwidth 40dB Bandwidth |
MHz MHz MHz |
21.6 – – |
22.5 23.05 27.6 |
28.2 |
| Amplitude Ripple (fo±10.0 MHz) Group Delay Variation (fo±10.0 MHz) |
dB nsec |
0.35 30 |
1 60 |
|
| Absolute Delay | usec | 0.73 | ||
| Ultimate Rejection | dB | 40 | 45 | |
| Temperature Coefficient of Frequency | ppm/°C | -86 | ||
